PRODUCT RANGE

→  Standard Wood Wool Insulation Boards / Slabs

DURATEX Standard Wood Wool Insulation Boards / Slabs, 15-100mm Thick stn'd width 600mm, length 1000 3000mm, Surface Texture : both in fine and course fibres. Weight : 8.5 - 36 Kg/m2 Thermal Resistance : 0.100-0.075 m2 K/W Bending Strength : 1.70 N/mm2

→ Composite "Multi-Layer" High Thermal-Insulation Boards / Slabs

DURATEX Standard Wood Wool Insulation Boards / Slabs, 50-150mm Thick stn'd width 600mm, length 1000-3000mm surface texture : both in fine and course fibres. Weight : 25-36 kg./m2 Thermal resistance : 0.60-2.80 m2 K/W Bending strength : 1.70 N/mm2

→ Special “Fire -Resistance-Rated" Boards / Slabs

DURATEX SPECIAL Fire-Resistance-Rated Boards / Slabs. having 1-Hr. , 2-Hr. , 4-Hr. rating, Fire-Seal CBRI (Fire Research Laboratory) Govt. of India, Ministry of Home Affairs approved.

→ Structural ”INTER-LOCKING” Steel Profile Edge Roof- Deck Slabs

DURATEX STRUCTURAL, "INTER-LOCKING" Steel Profile Edged Wall / Roof-Deck Slabs Length Max. 3000mm stn'd width 600mm, Thick 50 & 75mm.

→ High-Density Boards / Slabs

DURATEX High-Density Board/Slab for "Low-Cost", Mass-Housing Construction, Fixing Accessories, Quick Construction Technique provision for Architectural and Engineering designs "Superior World Class Technology".

SPECIFICATIONS

STANDARD DIMENSIONS & DENSITY OF WWCB :

Length : 600mm to 3000 mm
Width : 600 mm (2ft) (International Standard Width)
Thickness : 15mm, 25mm, 40mm, 50mm, 75mm, 100mm
Product densities typically vary from 340 – 570 kg/m3, subject to board thickness and application (thinner boards have a higher density than thicker boards).

SPECIFIC GRAVITY :

Light board for insulation only - 360 kg/m³
Denser boards for roofs and permanent shuttering - 450 kg/m³

INSULATION VALUE :

Light board for insulation only - y=0.06 kcal/n-1h°
Denser boards for roofs and permanent shuttering - y=0.07 kcal/mh°

BENDING STRENGTH :

20-30 kg/cm²

SOUND ABSORPTION :

For a suspended ceiling of 2.5 cm board
  - Frequency - 250   500   1000   2000   4000 c/s
  - Absorption Coefficient - 0,67   0,48   0,44   0,72   0,7

SOUND TRANSMISSION :

  - Resistance of a plastered wall of 5 cm w.w. boards 36-40dB
  - Resistance of a plastered double wall with air space in between  53-57 dB
  - Resistance of wall of permanent shuttering with a core of 12 cm concrete  54-56dB

FIRE RESISTANCE :

(Test Acc. to BS476) :5CM Board -  1 Hour Resistance
7.5CM Board -  2 Hour Resistance (12mm Plastered both-sides)
10CM Board -  2 Hour Resistance
